CASFLON™ 150 UL/cUL
Style 11063
Construction
Type
electrical wire
Core
bare, tin-plated, nickel-plated or silver-plated copper
Insulation
PFA
Thermal Characteristics
Operating temperature
-65°C to +150°C
Electrical Characteristics
Operating Voltage
600V
Testing Voltage
2000 V
Production
Range width
AWG 32 to 16
Options
Please consult us for any special requirements
Casmo Part No. | Wire gauge(AWG) | # Strands | Diam. Of Strands(mm) | Conductor Diameter(mm) | Wall thickness(mm) | Final O.D.(mm) | Approx, Wt.(kg/km) |
|---|---|---|---|---|---|---|---|
1210701 | 16 | 19 | 0.3 | 1.5 | 0.41 | 2.32 | 17.84
|
1210702
| 17 | 19 | 0.26 | 1.3 | 0.41 | 2.12 | 16.00 |
1210703 | 18 | 19 | 0.23 | 1.15 | 0.41 | 1.97 | 14.16
|
1210704 | 20 | 19 | 0.19 | 0.95 | 0.41 | 1.77 | 9.27
|
1210704 | 20 | 1 | 0.8 | 0.8 | 0.41 | 1.62 | 8.74 |
1210705 | 22
| 19 | 0.16 | 0.8 | 0.41 | 1.62 | 7.33
|
For more details, please download the sheet.
Downloads
Technical data sheet
General Characteristics
Weather conditions
excellent resistance to UV
Chemical behaviors
excellent resistance to aggressive chemical environments
Humidity
excellent resistance to humidity
Mechanical behaviors
excellent mechanical strength
Application
General use
excellent resistance to UV
Industry
cabling for industrial machines
Electromechanics
cabling for rotating machines
Household appliances
cabling for household electrical heating appliances
Frequently Asked Questions (FAQ)
With a 150°C rating and PFA insulation, it maintains performance in environments up to 150°C, preventing insulation breakdown and ensuring reliable power delivery in heaters or machinery exposed to heat.
Certified under UL and cUL standards, it simplifies regulatory approvals for US and Canadian markets, reducing delays in customs and ensuring seamless integration into UL-listed equipment.
Available in 36-2 AWG with solid or stranded tinned/bare copper, it allows tailoring for 600V applications, optimizing conductivity and flexibility to minimize voltage drop in custom industrial wiring.
Its horizontal flame resistance ensures quick self-extinguishing, reducing fire hazards in crowded control panels and complying with strict safety protocols to avoid downtime from electrical faults.
PFA insulation provides excellent resistance to oils, acids, and alkalis, extending cable lifespan in chemical processing plants and minimizing maintenance costs from corrosion.
